Model 420 423
Engine make and type Kubota D722 Kubota D902
Function 4-stroke 4-stroke
Coolant Water Water
Number of cylinders 3 3
Starter electric electric
Bore x stroke 67 x 68 mm 72 x 73,6 mm
Displacement 719 cm³ 898 cm³
Output (ECE R120) 14,9 kW (20 hp) 16 kW (22 hp)
Fuel diesel diesel
Fuel tank capacity 20 l 20 l
Engine oil type API CC API CC
Viscosity SAE 10W-30 SAE 10W-30
Engine oil capacity 3,8 l 3,7 l
Charging current max.
40 A 40 A
Tyres Tread
pattern
Part
no.
Pressure Machine width Fits with
snow chains
5 x 10 TR 65412 2,7 bar 990 mm 64055
23x8.50-12 GR 65045 2,0 bar 1050 mm 64455
23x8.50-12 TR 65046 2,0 bar 1050 mm 64455
23x10.50-12 GR 65047 2,0 bar 1095 mm 64745
23x10.50-12 TR 65048 2,0 bar 1095 mm 64745
Engine specification
Tyres
The loader can be equipped with different type of tyres for different operating conditions. Grass pattern (GR) tyres will
damage the ground surface less than tractor (TR) tyres, but provide less traction.
For the best stability and controllability, always use the largest tyres possible. Tyres that are narrower than the standard
tyres are intended for special purposes only with width restriction on the machine. Use only tyres and rims that meet
the original specifications and dimensions to avoid potential issues with load capacity, tyre size, or bearing load on
drive motors. Consult your dealer if further information is needed. Special tyres, such as studded wheels may also be
available. Consult your dealer for further information.
Auxiliary hydraulics oil flow
Max. auxiliary hydraulics oil flow can not be
used with all attachments. Check correct
engine rpm and auxiliary hydraulics pump
configuration for the attachment with the
help of this graph and the Operators Manual
of the attachment.
