AVANT CH100 - Page 35

35
CH100
CH100 CHIPPER
FARMI 100F
33
Part Order no Description Remarks Qty
1 52062041 Screw M12X50 DIN933 88ZN 4
2 52117124 Lock nut M12 DIN985 8ZN 7
3 52200490 Washer M12 DIN 7349 ZN 8
4 52062502 Screw M12X120 DIN931 88ZN 1
5 43340934 End plate 1
6 52211042 Spring washer M10 DIN127 ZN 1
7 52060209 Screw M10X16 DIN933 88ZN 1
8 52062015 Screw M12X20 DIN933 88ZN 4
9 52117900 Buttery nut M12 1
10 52062023 Screw M12X30 DIN933 88ZN 2
11 52060225 Screw M10X25 DIN933 88ZN 2
12 52200045 Washer M10 DIN125 58ZN 2
13 52117108 Lock nut M10 DIN985 8ZN 2
14 33620100 Disc 1
15 33620250 Lower chamber 1
16 33620350 Upper chamber 1
17 33620400 Discharge pipe 1
18 33620650 Drop spout 1
19 43620660 Bearing system 2
20 43620670 Anvil 1
21 43620690 Support for transport 1
22 43620700 Side anvil 1
23 33620850 Mounting frame 1
24 43343790 Drawbar 1
25 52062213 Screw M20X40 DIN933 88ZN 8
26 52117207 Lock nut M20 DIN985 8ZN 8
27 52062015 Screw M12X20 DIN933 88ZN 2
28 52117124 Lock nut M12 DIN985 8ZN 2
29 52062486 Screw M12x180 DIN931 88ZN 1
FARMI 100 CHIPPER
