4
CH100
When ordering spare parts, please indicate machines type from the machine plate, spare parts order number,
description and quantity required.
TABLE OF CONTENTS
GENERAL SAFETY INSTRUCTIONS 5
GENERAL SAFETY INSTRUCTIONS FOR THE CHIPPER 8
STICKERS AND PLATES 9
CH100 - GENERAL DESCRIPTION AND INTENDED USE 12
MOUNTING 14
LIFTING 14
ASSEMBLY INSTRUCTIONS 15
MOUNTING OF THE CHIPPER AND PRE-OPERATION INSPECTIONS 16
MOUNTING OF THE CHIPPER TO AVANT LOADER 17
CONNECTING AN DISCONNECTING HYDRAULIC HOSES
STARTING THE CHIPPER 22
CHIPPING 23
OPERATION OF CHIPPER AND FEED UNIT 23
EMPTYING THE CHIPPER AFTER USE 24
SWIVELING THE FEED HOPPER TO THE TRANSPORT POSITION 24
STORAGE OF THE CHIPPER 24
MAINTENANCE 24
REPLACING THE BEARING 25
ADJUSTING THE BEARING CLEARANCE 26
KNIFE AND ANVIL MAINTENANCE 29
CH100 CHIPPER 34
DISC, COMPLETE 36
CH100 BEARINGS 37
BELT DRIVE FARMI 100F i=2,0 38
DISCHARGE CHUTE 40
HYDRAULIC MOTOR AND HOSES, OPTIONAL EQUIPMENT 41
CH100 HYDRAULIC OPERATION, OPTIONAL EQUIPMENT 42
PRODUCT REGISTRATION FORM 46
