41
CH100
1
7
5
8
6
4
3
2
Part Order no Description Remarks Qty
1 56001310 Hydraulic motor M+S 1
2 56001320 Pressure relief valve 80 bar
1
3 52001280 Screw M12X20 DIN933 88ZN 4
4 52450020 Basic connector 1/2” 1
5 52450030 Angle connector 1/2” 1
6 43621330 Hydraulic hose L=1350 2
7 43621340 Hydraulic hose L=1350 1
8 03621350 Multiconnector 1/2” 1
HYDRAULIC MOTOR AND HOSES
