39
CH100
BELT TRANSMISSION CH100 i=2,0
Part Order no Description Remarks Qty
1 53220570 Belt pulley D315 1
1.1 43621220 Splined shaft 1
2 43514450 Bearing housing 1
3.1 53220590 Belt pulley D150 1
3.2 53220580 Tapered adapter sleeve 1
3.3 53220560 Taper bushing 1
3.4 43341437 Pile 1
4 54822382 Belt 3
5 43512020 Belt tightener complete 1
5.1 43512030 Belt tightener 1
5.2 43341106 Reel 1
5.3 52840055 Cotter pin 5X50 DIN1481 1
5.4 43341114 Pin 1
5.5 54511134 Slotted sealed ball bearing 2
6 43341114 Pin 1
7 52063658 Screw M12X20 DIN933 88ZN 1
8 43511950 Pin 1
9 43512050 Adjusting plate 1
10 52090560 Screw M12x30 DIN933 10.9 4
11 52117124 Lock nut M12 DIN985 8ZN 4
12 33621380 Cover plate 1
13 43511780 Cover of the universal shaft 1
14 52060126 Screw M12X20 DIN933 88ZN 4
15 52117082 Lock nut M12 DIN985 8ZN 6
16 43402150 Spring 1
17 54512140 Ball bearing 2
18 52230257 Circlip 45x2,5 DIN471 1
19 52200466 Washer M10 DIN127 ZN 4
20 52200037 Washer M12 DIN985 8ZN 6
21 52840055 Cotter pin 5X50 DIN1481 2
22 52021250 Locking bolt M12X20 DIN933 88ZN 2
