230 Installation and Configuration Guide Avaya C360 Multilayer Stackable Switches, version 4.5

Console Pin Assignments

For direct Console communications, connect the C360 to the Console Terminal using the

supplied RJ-45 crossed cable and RJ-45 to DB-9 adapter.

Tip:

Tip: Pin 1 of the Modem DB-25 connector is internally connected to Pin 7 GND.

C360 RJ-45 Pin Name

(DCE View)

Terminal

DB-9 Pins

Modem

DB-25 Pins

1 For future use NC See note

2TXD

(C360 input)

3RXD

(C360 output)

4CD48

5GND57

6DTR120

7RTS84

8CTS75
