Avaya VSP 7000 Series Installing

LED State Description
Emerald / Amber
(Alternating)
The power supply in slot 2 is operating, but
the airflow mode does not match the power
supply in slot 1. You must replace the power
supply to match the airflow.
FA1 / FA2 Ruby (Solid) If both fan LEDs are ruby, the unit shut down
from an over-voltage fault or an over-
temperature fault.
For an over-voltage fault, the unit shuts down
within 4 seconds. For an over-temperate
fault, the unit shuts down immediately.
Note:
The unit software monitors the internal
temperature and generates log and
SNMP traps to indicate that the unit is
running above the high-temperature
threshold and is approaching a critical
over-temperature fault.
Ruby (Blinking) The fan tray in position 1 or 2 is missing. You
must install a fan tray, and the fan tray must
match the airflow mode of the power supply.
Ruby (Fast Blinking) The fan tray in position 1 or 2 is connected
but is not operating. Replace the failed fan
tray.
Sapphire (Solid) The fan tray in position 1 or 2 is front to back
airflow and is operating normally.
Sapphire (Blinking) The fan tray in position 1 or 2 is front to back
airflow and has degraded. Check for a fan
failure and replace if necessary.
Amethyst (Solid) The fan tray in position 1 or 2 is back to front
airflow and is operating normally.
Amethyst (Blinking) The fan tray in position 1 or 2 is back to front
airflow and has degraded. Check for a fan
failure and replace if necessary.
Amethyst / Ruby
(Alternating)
The fan tray in position 1 or 2 does not match
the front to back airflow mode of the power
supply. You must replace the fan tray with a
front to back airflow model.
Sapphire / Ruby (Alternating) The fan tray in position 1 or 2 does not match
the back to front airflow mode of the power
supply. You must replace the fan tray with a
back to front airflow model.
Sapphire (Blink x3) / Ruby
(Solid)
The fan tray in position 1 or 2 has degraded
and does not match the front to back airflow
mode of the power supply. You must replace
Checking status LEDs to verify switch installation
August 2014 Installing Avaya VSP 7000 Series 37
