AVer DL30 - Device Connections

5
Device Connection
Lecture Capture System
DL Tracking Camera
PoE+ IEEE802.3at
HDMI (Not for DL30)
or
LAN
(Record)
Laptop/Desktop
(Management/Presentation)
Monitor/TV
(Display)
Microphone
Audio Input
USB
CaptureShare
Web Application
(Remote Management)
PTZ Management
PoE+ Connection
Connect the camera to the router or switch through the PoE+ port.
[Note] Only support IEEE 802.3at PoE+ standard.
Router/PoE+ Switch
Ethernet cable
(Not included)
