23
2. Select the block and set the preset positions in order (preset 6 to preset 9). Use , ,
, , and to move the camera to wanted position and select “Save” to save
the preset position. And, a snapshot of the preset image will show at corresponding image display
box. Repeat the steps to set another preset position.
[Notes]
Set each preset overlapping with the next one (one man width).
Set the preset view to clearly see at least 60% upper body of the presenter to ensure tracking
accuracy. Make sure no other human-outline poster/TV/monitor in the background.
3. Tracking Sensitivity: sets the sensitive level of tracking. Move bar to set the value. The current
value is displayed at upper right corner.
4. Time of Return to Tracking Point: sets the idle time for camera return to tracking point. Move bar
to set the value. The current value is displayed at upper right corner.
