13
Step 3
Adjusting the Rotary Knob
Adjust the rotary knob attached to the inner side of the lid to fit the height of your HDD.
The default position of the rotary knob fits HDD with 9.5 mm height. If you use a 7 mm HDD, rotate the
rotary knob to the other direction. For a 12.7 mm HDD, you need to remove the rotary knob using a
screwdriver.
Using a 7 mm HDD:
Using a 9.5 mm HDD:
Using a 12.7 mm HDD:
 The device with measurement marked on the inner HDD lid may vary by region. Please read the instructions according
to the device purchased.
