S6L-24C and S6L-16C 31
S6L-24C/16C Only
5 While holding down the Control key on the USB keyboard, right-click (or touch and hold) on the S6L Control Surface icon and
choose
Pair Console to AVB Card from the pop-up menu.
6 If any devices, modules, or components do not seem to be functioning, power down all components and then check connections
to the new SBC.
7 Proceed to 6. Complete the Installation.
6. Complete the Installation
After confirming a successful installation of the new SBC, re-install the upper and lower back covers to complete the installation.
For details and illustrations, refer to the earlier instructions for disassembly.
To re-assemble the S6L-24C and 16C:
1 Shut down the S6L control surface, then power off the control surface and your other S6L components.
2 Reconnect the light cables (refer to Disconnect Light Cables).
3 Reinstall the top panel and secure it with the 4 fasteners you removed earlier.
4 Reinstall the back cover and secure it with the fasteners you removed earlier.
5 If you loosened or removed one or both End Caps, re-install them and tighten their fasteners. If you removed either or both End
Caps, be sure to re-connect the LED cable(s).
Your S6L control surface is now ready for use.
