S6L-24C and S6L-16C 27
S6L-24C/16C Only
Reconnecting All cables
To reconnect cables:
Reconnect cables as per the following table. (For a diagram identifying ports on the SBC, see S6L SBC Ports.)
Cables are listed by Part Number, which is printed on each cable.
• Be especially careful with the braided cables that have identical connectors/headers (follow instructions below for correct ori-
entation), and with the two RJ-45 cables (one Ethernet jumper connects the S6L AVB card to the left-most RJ-45 port, the
other jumper connects the S6L ECx port to the right-most RJ-45 port.
* Two port IDs “Lower” and “Upper” are provided for port X16, since this port receives two separate cables. Orientation (lower
or upper) is while standing at the back of the control surface. Be sure to connect each cable to its correct port, and to orient the cable
as described in the table above.
S6L Control Surface SBC Cable Labels
Congatec SBC
Port IDs /
Cable PN (newer units)
Source / Notes
X19J2
(7070-30554-00)
Back panel DVI
X49
(7070-30597-00)
PDB J2
X5 J2
(7070-35031-00)
Switch
X6 J2
(7070-35029-00)
Back panel ECx RJ45
X39J2X
(7070-30621-00)
Carbon 2 J32
X25J2
S6L-48D/32D/24D: (7070-35148-00)
S6L-24C: (7070-35149-00)
MTS CN1 (LVDS cable)
Orient cable so white wires are closest to you (see
Figure 42)
(n/a for S6L-16C)
X22J2
(7070-35147-00)
GPIO J11
X16 Lower
(7070-30616-01)
CON 1 Touch Controller
Orient cable so black wire is to the right (see
Figure 43)
(n/a for S6L-16C)
X16 Upper
(7070-30593-00)
From MIDI J11
Orient cable so black wire is to the right (see
Figure 43)
X15J2
(7070-30563-00)
Back Panel Dual USB
X13J2
(7070-30618-00)
Front Panel Dual USB Mount
To Next Page
