Stage and Local I/O Rack Overview 51
Stage 64 and Stage 32 I/O Card Features and Capabilities
You can install variety of analog and digital I/O cards in Stage 64 and Stage 32. You can purchase a pre-configured unit and modify
card configurations, or purchase an empty Stage 64 or Stage 32 and configure your rack as desired. For instructions on installing
I/O cards, see the
S6L Stage I/O Card Installation Guide (for Dante card installation, see the DNT-192 Network Card.pdf).
SRI-192 Analog Input Card
• Eight channels of analog mic/line inputs via XLR-3 female connectors
• +48V phantom power, 20 dB pad, and phase reverse (all selectable per channel via the control surface and VENUE software)
• Signal and phantom power LEDs for each channel
• 24-bit A/D conversion, up to 192 kHz sample rate
DSI-192 Digital Input Card
• Eight channels of digital inputs via four two-channel AES/EBU XLR3-female connectors or a single ADAT TOSLINK opti-
cal connector
• Automatic sample rate conversion (SRC) and detection on input; manually defeatable for lowest possible input latency
• SRC and Lock status LEDs for both AES and ADAT connections
• Word clock output for synchronizing external digital devices
SRO-192 Analog Output Card
• Eight channels of analog line outputs via male XLR-3 connectors
• Automatic muting for system protection
• Signal and Mute LEDs for each channel
• 24-bit D/A conversion
DSO-192 Digital Output Card
• Eight channels of digital outputs via four two-channel AES/EBU XLR3-male connectors and/or a single ADAT TOSLINK
optical connector
• Simultaneous output to both AES/EBU outputs and ADAT optical output
• Automatic muting for system protection
• Signal and Mute LEDs for each AES/EBU channel pair
DNT-192 Network Card
• Sixteen channels of digital input or output, or eight input and eight output channels (Stage 64 only), for connecting to Dante
network devices.
See Working with DSI-192 Digital Inputs for information on working with DSI ADAT and SRC functionality.
