Surround1 Inputs
Surround2 Inputs
Signal Name Pin# Signal Type
24 Input+
12 Input-
Surround Input1-1
25 GND
10 Input+
23 Input-
Surround Input1-2
11 GND
21 Input+
9 Input-
Surround Input1-3
22 GND
7 Input+
20 Input-
Surround Input1-4
8 GND
18 Input+
6 Input-
Surround Input1-5
19 GND
4 Input+
17 Input-
Surround Input1-6
5 GND
15 Input+
3 Input-
Surround Input1-7
16 GND
1 Input+
14 Input-
Surround Input1-8
2 GND
13
26
GND
27
GND
Signal Name Pin# Signal Type
24 Input+
12 Input-
Surround Input2-1
25 GND
10 Input+
23 Input-
Surround Input2-2
11 GND
21 Input+
9 Input-
Surround Input2-3
22 GND
7 Input+
20 Input-
Surround Input2-4
8 GND
18 Input+
6 Input-
Surround Input2-5
19 GND
4 Input+
17 Input-
Surround Input2-6
5 GND
15 Input+
3 Input-
Surround Input2-7
16 GND
1 Input+
14 Input-
Surround Input2-8
2 GND
13
26
GND
27
GND
