Avid Technology XMON EUCON User Manual

Chapter 2: Installing XMON 11
2Track Inputs
Cue Outputs
Signal Name Pin# Signal Type
24 Input+
12 Input-
2Track Input1
25 GND
10 Input+
23 Input-
2Track Input2
11 GND
21 Input+
9 Input-
2Track Input3
22 GND
7 Input+
20 Input-
2Track Input4
8 GND
18 Input+
6 Input-
2Track Input5
19 GND
4 Input+
17 Input-
2Track Input6
5 GND
15 Input+
3 Input-
2Track Input7
16 GND
1 Input+
14 Input-
2Track Input8
2 GND
13
26
GND
27
GND
Signal Name Pin# Signal Type
24 Output+
12 Output-
SLS Output L
25 GND
10 Output+
23 Output-
SLS Output R
11 GND
21 Output+
9 Output-
Cue Output1L
22 GND
7 Output+
20 Output-
Cue Output1R
8 GND
18 Output+
6 Output-
Cue Output2L
19 GND
4 Output+
17 Output-
Cue Output2R
5 GND
15 Output+
3 Output-
Cue Output3L
16 GND
1 Output+
14 Output-
Cue Output3R
2 GND
13
26
GND
27
GND
