Avid Technology XMON EUCON User Manual

XMON EUCON Software Application User Guide12
Main SPK Outputs
Alt SPK Outputs
Signal Name Pin# Signal Type
24 Output+
12 Output-
Main 1 (L)
25 GND
10 Output+
23 Output-
Main 2 (Lc)
11 GND
21 Output+
9 Output-
Main 3 (C)
22 GND
7 Output+
20 Output-
Main 4 (Rc)
8 GND
18 Output+
6 Output-
Main 5 (R)
19 GND
4 Output+
17 Output-
Main 6 (SurL)
5 GND
15 Output+
3 Output-
Main 7 (SurR)
16 GND
1 Output+
14 Output-
Main 8 (LF)
2 GND
13
26
GND
27
GND
Signal Name Pin# Signal Type
24 Output+
12 Output-
Alt 1 (L)
25 GND
10 Output+
23 Output-
Alt 2 (Lc)
11 GND
21 Output+
9 Output-
Alt 3 (C)
22 GND
7 Output+
20 Output-
Alt 4 (Rc)
8 GND
18 Output+
6 Output-
Alt 5 (R)
19 GND
4 Output+
17 Output-
Alt 6 (SurL)
5 GND
15 Output+
3 Output-
Alt 7 (SurR)
16 GND
1 Output+
14 Output-
Alt 8 (LF)
2 GND
13
26
GND
27
GND
