Avid Technology XMON EUCON User Manual

Chapter 2: Installing XMON 13
TB/LB
Signal Name Pin# Signal Type
24 Input+
12 Input-
TB Input2
25 GND
10 Input+
23 Input-
LB Input1
11 GND
21 Input+
9 Input-
LB Input2
22 GND
7 Input+
20 Input-
AFL Input1
8 GND
18 Input+
6 Input-
AFL Input2
19 GND
4 Output+
17 Output-
Mini Spk L
5 GND
15 Output+
3 Output-
Mini Spk R
16 GND
1 Output+
14 Output-
TB OUT
2 GND
13
26
GND
27
GND
