AVM FRITZ!WLAN USB Stick User Manual

FRITZ!WLAN USB Stick 51
Obtaining an IP Address Automatically in Windows 7
Proceed as follows in Windows 7:
1. Click the “Start” button in the task bar and select the
“
Control Panel / Network and Internet”.
2. Under “Network and Sharing Center”, click “View net-
w
ork status and tasks”.
3. From the left column, select the “Change adapter
setti
ngs” command.
4. Click the wireless network connection icon with the
ri
ght mouse button and select “Properties”.
5. Under “This connection uses the following items”,
sel
ect the “Internet Protocol Version 4 (TCP/IPv4)”
en
try and click “Properties”.
6. On the “General” tab, enable the options “Obtain an
I
P address automatically” and “Obtain DNS server
address automatically”.
Properties of the Internet protocol (TCP/IP)

AVM FRITZ!WLAN USB Stick Specifications

General

Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Data link protocols	IEEE 802.11b, IEEE 802.11g, IEEE 802.11g++
Security algorithms	WPA, WPA2
Maximum data transfer rate	125 Mbit/s
Dimensions (WxDxH)	132 x 138 x 35 mm
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i
Supported data transfer rates	11 Mbit/s, 54 Mbit/s, 125 Mbit/s
Compatible operating systems	Windows Vista x64 Edition, Windows Vista, XP Professional x64 Edition, Windows XP/2000
Connectivity technology	Wireless
Component for	PC/Laptop

Weight and Dimensions

Weight	125 g
