AVM FRITZ!WLAN USB Stick User Manual

FRITZ!WLAN USB Stick 38
Allocation of the WLAN Channels in the 2.4-GHz Range
6.4 WPS (Wi-Fi Protected Setup)
The FRITZ!WLAN USB Stick supports the standardized WPS
networking procedure (Wi-Fi Protected Setup). With WPS
you can establish a secure WLAN connection between
your FRITZ!WLAN USB Stick and your WLAN access point.
A
l
l of the necessary WLAN security settings are transferred
in the process.
When establishing a WLAN connection via WPS you can
use ei
ther the push-button or the PIN method:
• For the push-button method (WPS-PBC) your WLAN
access point must be equipped with a hardware or
software switch that is used to enable WPS function-
ality.
• For the pin method, you enter the PIN specified by
the FRITZ!WLAN USB Stick in the WPS data of your
WLA
N access point.
WPS can be used only in combination with WLAN access
points that also support WPS. See the documentation of
your WLAN access point to find out whether it supports
WPS and which connection methods can be selected.
Channel Frequency (GHz) Channel Frequency (GHz)
1 2.412 8 2.447
2 2.417 9 2.452
3 2.422 10 2.457
4 2.427 11 2.462
5 2.432 12 2.467
6 2.437 13 2.472
7 2.442

AVM FRITZ!WLAN USB Stick Specifications

General

Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Data link protocols	IEEE 802.11b, IEEE 802.11g, IEEE 802.11g++
Security algorithms	WPA, WPA2
Maximum data transfer rate	125 Mbit/s
Dimensions (WxDxH)	132 x 138 x 35 mm
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i
Supported data transfer rates	11 Mbit/s, 54 Mbit/s, 125 Mbit/s
Compatible operating systems	Windows Vista x64 Edition, Windows Vista, XP Professional x64 Edition, Windows XP/2000
Connectivity technology	Wireless
Component for	PC/Laptop

Weight and Dimensions

Weight	125 g
