AVM FRITZ!WLAN USB Stick User Manual

FRITZ!WLAN USB Stick 11
2AVM Stick & Surf Technology
Connecting Securely with a FRITZ!Box
With the AVM Stick & Surf technology the FRITZ!WLAN USB Stick can
take over the WLAN security settings from FRITZ!Box products. This
allows a secure WLAN connection to be established between your com-
puter and your FRITZ!Box without any additional configuration.
For this, your FRITZ!Box must be equipped with a port for
USB de
vices (USB host function).
In order to use the AVM Stick & Surf technology for secure
WLAN
connections, perform the following steps:
1. Insert the FRITZ!WLAN USB
Stick into the USB port on
your FRITZ!Box.
Port for USB devices (here on the FRITZ!Box Fon WLAN 7270)
2. The FRITZ!Box “Info” LED begins flashing to indicate
that the WLAN security settings are being transmitted
to the FRITZ!WLAN USB Stick.
3. When data transmission has been completed, the
“
Info” LED stops flashing on the FRITZ!Box and re-
mains lit.
4. Remove the FRITZ!WLAN USB
Stick from the
FRITZ!Box USB port.
The WLAN security settings have now been transmitted to
the F
RITZ!WLAN USB Stick.

AVM FRITZ!WLAN USB Stick Specifications

General

Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Data link protocols	IEEE 802.11b, IEEE 802.11g, IEEE 802.11g++
Security algorithms	WPA, WPA2
Maximum data transfer rate	125 Mbit/s
Dimensions (WxDxH)	132 x 138 x 35 mm
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i
Supported data transfer rates	11 Mbit/s, 54 Mbit/s, 125 Mbit/s
Compatible operating systems	Windows Vista x64 Edition, Windows Vista, XP Professional x64 Edition, Windows XP/2000
Connectivity technology	Wireless
Component for	PC/Laptop

Weight and Dimensions

Weight	125 g
