AVM FRITZ!WLAN USB Stick User Manual

FRITZ!WLAN USB Stick 16
5. Then click “Yes” (Windows 7) or “Continue”
(Windows Vista) in the “User Account Control” dia-
log.
6. In the “Found New Hardware” window, select “Locate
and
install driver software (recommended)”.
If Windows reports that the program may not have
be
en installed correctly, click “The Program was in-
stalled correctly.” or “Cancel”.
7. Then click “Yes” (Windows 7
) or “Continue”
(Windows Vista) in the “User Account Control” dia-
log.
8. If Windows asks whether you would like to search for
d
rivers online, select the “Do not search for drivers
online” option.
9. Insert the FRITZ!WLAN USB S
tick CD when Windows
prompts you to do so.
The driver software is installed automatically.
This completes the driver installation for the
FRI
TZ!WLAN USB Stick. Continue reading from section “In-
formation on WLAN Connections” on page 18.
3.4 Installation in Windows XP 32-bit Edition
Administrator rights are required to install the
FRITZ!WLAN
USB Stick in Windows XP!
Perform the following steps to install the software:
1. Switch on the WLAN device you wish to connect to.
2. Switch on your computer.
3. Insert the FRITZ!WLAN USB
Stick into the USB port on
your computer.
Windows detects the FRITZ!WLAN USB Stick automat-
ically. This process may take some time.

AVM FRITZ!WLAN USB Stick Specifications

General

Wi-Fi	Yes
Wi-Fi band	Single-band (2.4 GHz)
Data link protocols	IEEE 802.11b, IEEE 802.11g, IEEE 802.11g++
Security algorithms	WPA, WPA2
Maximum data transfer rate	125 Mbit/s
Dimensions (WxDxH)	132 x 138 x 35 mm
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11i
Supported data transfer rates	11 Mbit/s, 54 Mbit/s, 125 Mbit/s
Compatible operating systems	Windows Vista x64 Edition, Windows Vista, XP Professional x64 Edition, Windows XP/2000
Connectivity technology	Wireless
Component for	PC/Laptop

Weight and Dimensions

Weight	125 g
