THE DISPLAY, AT A GLANCE
The following diagrams depict the front, side, and bottom panels of the display. The physical interface and
connections are labeled, and then described in the tables that follow.
Front Panel
Microphone Array
4 microphones
Front Panel Interface
See Page 11 for more details.
IR Sensor / Light Sensor
See Page 11 for more details
Pen Holder
Magnetized pen storage.
PR Sensor
See Page 12 for more details
