AVG Series User Manual | 14
Bottom-Rear Panel Inputs
RS232C
DB9 Female Input
For interfacing with a PC or
automation/control system.
Ethernet Out
RJ45 Output
Lan Out, 10/100Mbps.
Ethernet In
RJ45 Input
Lan In, 10/100Mbps.
Service Port
USB Type A Connector
Connect a USB stick for firmware
upgrade.
