AVOCOR AVG Series User Manual

AVG Series User Manual | 8
SPECIFICATIONS
Model
AVG-6560
AVG-7560
AVG-8560
LCD Panel
Diagonal Size (Inches)
65
75
85
Backlight
Direct-lit LED
Aspect Ratio
16:9
Resolution
3840 x 2160 @ 60Hz
Response Time
9.5 ms
Brightness
400 (cd/m2)
400 (cd/m2)
400 (cd/m2)
Contrast Ratio
5000:1
5000:1
5000:1
Viewing Angle
178°/178°
Supported Colors
1.07 Billion Colors
Display Orientation
Landscape
Touch System
Touch
Up to 20 Point Avocor Intelligent Touch – Supports 4 fine tip stylus
Glass
3.2 mm AG & AF Coating Tempered Glass
Supported OS
Windows 7 Pro, 8, 8.1 & 10; Mac OS 10.1 or later; Linux based OS Kernel 3.15 or later
Connectivity
Rear Inputs
2x USB 3.0, 1x Type-C, 1x DisplayPort 1.2, 2x HDMI 2.0, 3x USB-B Touch 3.0
Other Inputs
3x HUB USB 3.0, 1x USB Service Port 2.0, 1x HDMI Out
Audio
1x Audio Out, 1x SPDIF Out
Control
1x IR in, 1x LAN Ethernet in, 1x LAN Ethernet out, 1x RS232C
OPS Slot
Yes, 3840 x 2160 @ 60Hz
Audio
Built-in Speakers
2x 15W
MIC Array
4 Microphones, operating distance up to 5m
Sensors
IR Sensor
3 ± 0.5m
PR Sensor
3.5 ± 0.5m
Display Functions
Auto-source detection, Source Preview
Physical Specifications
Product Dimensions
1481.4 x 884.4 x 116mm
58.3 x 34.8 x 4.6 in
1703.5 x 1009.2 x 116.8 mm
67.1 x 39.7 x 4.6 in
1929.5 x 1138.5 x 117.2 mm
76 x 44.8 x 4.6 in
Weight
Net: 56 kg / 123.4 lbs
Gross: 75.5 kg / 166.5 lbs
Net: 71.6 kg / 157.9 lbs
Gross: 100 kg / 220.5 lbs
Net: 91.3 kg / 201.3 lbs
Gross: 124 kg / 273.4 lbs
Wall Mount (VESA)
400 x 400 mm
600 x 400 mm
600 x 400 mm
Mini PC Mount
100 x 100 mm
Handles (Removable)
4
Power
Power Supply
AC100 – 240V (Worldwide)
Max 5.0A, 50/60Hz
Max 6.2A, 50/60Hz
Max 7.2A, 50/60Hz
Max Power Consumption
335W (Non-OPS)
395W (Non-OPS)
480W (Non-OPS)
Standby
≤0.5W
Environmental
Operating Temperature
0°C ~ 40°C / 32° F ~ 104° F
Storage Temperature
-20° C ~ 60° C / -4° F ~ 140° F
Humidity
35% ~ 85%
