AVG Series User Manual | 20
Mounting the Display
You can mount the display on a wall. If you do decide to wall-mount the display, ensure that the wall-mount
bracket is installed according to the instructions included with it. The wall must be capable of supporting a
redundant weight factor three (3) times the weight of the display, or be reinforced.
NOTE
➢ Leave mounting to the installation specialists.
➢ Always make sure that your stand, or mount/wall is rated to hold the weight of your
display.
➢ Make sure that the surface you place the mount or stand upon can support the
weight of your display.
➢ Make sure the tilt degree of the display does not exceed 2°.
➢ Always get help when moving or mounting the display.
o 2 people are needed for displays up to 65”
o 3 people are needed for displays up to 75”
o 4 people are needed for displays up to 85”
WALL MOUNT
Follow the manual instructions for the type of mount you have selected. Refer all servicing to qualified
service personnel.
Moving the display requires at least two people. Make sure you use the handles in the back of the display
while lifting or moving the display, to avoid touching the front panel during the move.
Before installing, please make sure the wall is strong enough to hold the necessary weight of the display and
the mount.
Step1. Keep the display facing the ground and place it on a flat object.
Step2. Remove the screws (M8*15) from the back of the display.
Step3. Align the wall brackets with the mounting holes and attach the brackets to the display using the
screws removed in Step 2.
Longer screws will damage the display.
VESA Mount Dimensions:
AVG-6560 : 400 x 400mm
AVG-7560 / AVG-8560 : 600 x 400mm
