5.4.8 DCCS
Note: This function is for selected models only.
Note: DCCS is supported only for CH1. Make sure you’ve connected a DCCS-enabled camera to the
video channel of CH1, and you see “ ” in the channel status bar.
ADVANCED CONFIG
CAMERA CH1 CH2 CH3
CH4
CH5
CH6
CH7
CH8
CH9
CH10
CH11
DETECTION DIAGNOSTIC START
ALERT MENU SETUP
NETWORK
DISPLAY
RECORD
DEVICES DEVICE AVK523
DCCS CONNECTION OK
IVS
NOTIFY
EXIT
1) DIAGNOSTIC
Click “START” to start examining the DCCS signal transmission between the DVR and the camera. The
result will display in “CONNECTION”.
2) MENU
Click “SETUP” to configure the connected zoom lens control camera.
Different zoom lens control cameras might have different parameter settings. For details, please refer to their
own user manuals.
Note: While configuring the camera parameters, the DVR will switch to the corresponding channel, and
you can simultaneously preview the effects for the settings.
3) DEVICE
Here shows the model number of the camera.
4) CONNECTION
Here shows the examining result for DCCS signal transmission between the DVR and camera. The
message is as follows:
MESSAGE SHOWN MEANING
CHECKING The DVR is checking the DCCS signal transmission between the DVR and camera.
OK The signal transmission is fine and the DCCS function works properly.
FAIL The signal transmission is too weak or not available for the DCCS function to work properly.
