Control Block Description ADDvantage-32
4-44
1. Inputs
Reference FAX-32 digital inputs on J2 of board.
2. Outputs
START: BIT
3. Implementation
The digital input for USER 7 through USER 14 will equal ONE/ON when the input’s
corresponding FAX-32 J2 terminal is switched to +24 VDC.
The digital input for USER 7 through USER 14 will equal ZERO/OFF when the input’s
corresponding FAX-32 J2 terminal is switched to 0 VDC.
