ADDvantage-32
Advanced Control Module (ACM)
9-11
CHECKSUM AREA
ELEMENT NUMBER
Drive Calibration 0
Control Calibration 1
Drive Configuration 2
Control Configuration 3
Calibration 4
Analyzer Calibration 5
Analyzer Configuration 6
9.3.33 FILE 41 - CAL VERSION
This file consists of one integer element containing the
version number of the calibration data.
9.3.34 FILE 42 - SOFTWARE PART NUMBER AND VERSION NUMBER
This file contains the part number and version number for the
particular version installed in the unit.
The table is organized as two bytes per element with two
integer elements. They are organized as:
Part Number Element 0
Version Element 1
Reading this file would return the part number and version
number of the installed software.
9.3.35 FILE 43 - TIME ARRAY
This file is organized as two long integer values of four
bytes each. The lower element value is a time reference that
may be written with a time reference value by the master
station. If it is not written to, it will default to a value
of zero (0). The upper element value will be incremented six
times for each line cycle after the time reference is set.
Each element is an unsigned long integer value. (Refer to
section 6.2 of ER 14363-001 for recovery and writing to
elements containing long integers.)
Integer 0 - Time reference value
Integer 1 - Time intervals since last time reference.
9.3.36 FILE 44 - ANALYZER CAL LABELS
This file contains the analyzer calibration labels. Each of
the four groups (Channels 1 through 4) is made up of eight
elements.
For example:
First element - TRIG LEVEL 1
Next element - RATE 1
