ADDvantage-32
Advanced Control Module (ACM)
9-7
Reading the first element returns the following data:
..... 5AH 45H 52H 4FH 20H 41H 4EH 42H 4CH 4FH 47H ....
Z E R O A N A L O G
9.3.11 FILE 19 - CONTROL CAL HI LIMS
This file contains all of the predefined high limit values
for each control calibration value.
9.3.12 FILE 20 - CONTROL CAL LO LIMS
This file contains all of the predefined low limit values for
each control calibration value.
9.3.13 FILE 21 - CONTROL CAL DEFAULTS
This file contains all of the predefined default values for
control calibration.
9.3.14 FILE 22 - CONTROL CONFIG LEGALS
This file contains the drive configuration legal and is
organized as a two-dimensional array of eight integer values
per element with 139 elements maximum. Each element of eight
values represents the legal choices that may be selected for
that particular element of configuration in File 25.
9.3.15 FILE 23 - CONTROL CFG LABELS
This file contains the drive configuration labels. One
element is used to produce one label.
For example:
First element - JOG REF
Next element - MASTER REF
9.3.16 FILE 24 - CONTROL CAL UNITS
This file contains the units associated with each of the
labels defined for the control calibration values. One
element is used to define one unit.
9.3.17 FILE 25 - CONTROL CONFIG
This file contains the control configuration data for the
particular drive software version and part number.
9.3.18 FILE 26 - DEFAULT CONTROL CAL UNITS
This file contains all of the predefined default units for
control calibration. One element is used to define one unit
definition.
For example:
First element - UNITS
Next element - UNITS
9.3.19 FILE 27 - CONTROL CAL
This file contains all of the calibration values for each
control calibration entry. Each element contains one
calibration value in floating point format. This file will
To Next Page
