Control Block Description ADDvantage-32
4-52
4.36 GAIN
The Gain block is used to scale and offset an analog signal.
FIGURE 4-36. GAIN BLOCK
1. Inputs
INP: Analog
GAIN: Analog
OFF: Analog
2. Outputs
OUT: Analog
3. Implementation
OUT = INP × GAIN + OFF
