Installation
6 Installation Guide - Model 60E
Plug the monitor power cable into a grounded AC mains power socket. The
monitor does not require low voltage power.
2.2.5 - Power On
The power switch on the rear panel controls the power supply to the AX3000.
1 : On
0 : Off
The green LED on the front of the terminal should light, and a single audible
beep should be heard, to indicate that the AX3000 terminal is powered up and
operating correctly.
To indicate correct keyboard initialisation after power-up, the keyboard indicator
lights 'Num lock', 'Caps lock' and 'Scroll lock' should flash twice.
The green LED on the right side of the RJ45 connector on the back panel
remains lit, to indicate a satisfactory Ethernet connection.
If the terminal does not function as described above (for example if it emits a
continuous tone sound, or two beeps, or if an error message is displayed on the
screen) refer to chapter 5. If the terminal still does not operate properly, call
your service representative.
