Axis 200 - Controlling and Monitoring

Appendix E: The Auxiliary IO Port AXIS 200 User’s Manual
74
Caution!
GND on the IO connector is not connected directly to the power
connector. Always use two independent power sources! Connecting
GND to the power connector will permanently damage your AXIS
200.
Controlling and Monitoring
IO Files
The status of the input/output interface can be monitored and
controlled by the IO software within your AXIS 200. From your Web
browser, you can access the IO control file in order to either drive the
relay output or monitor the status of the digital inputs.
To access the IO file, enter the following URL:
You will require
root
access to reach these files and will now be asked
to supply a user name and password. Login as
root
and supply the
root password (default =
pass
).
Once access is granted, the following files are displayed:
Relay Output
You can use the relay output to drive directly a maximum load of 24V
AC/DC at 100mA. By connecting additional relay circuitry, you can
also use this output to drive heavier loads.
You can drive the relay off and on simply by clicking
relayoff.txt
or
relayon.txt
in the above URL. Clicking on either of these will
return either of the following messages, respectively:
http://cameraname/io/
relayon.txt
relayoff.txt
input.txt
Relay is Off
Relay is On
