opposite side of the boat. For
example, when the left wake is
desired, select the left arrow;
the right/starboard gate will be
the gate that will deploy. The
gate will deploy only between
the speeds of seven (7) mph
and thirteen (13) mph. While
the boat is underway, the surf
wake can be transferred from
one side to the other in less
than three (3) seconds. While
the transfer is occurring, there
is an indicator horn on the tran-
som that signals to boarders/
surfers when the surf wake is
about to transfer from one side
to the other.
Because the gates can function independently of each other, it is important for people on
board to pay attention to how the boat is leaning. Unlike earlier methods for creating a surf
wake, with Surf Gates the surf wake will be at optimal performance when the boat is weighted
evenly. If too much ballast, gate and passengers are loaded to one side or the other, it could cre-
ate an unstable situation in which the boat could become swamped. Always use common sense
and good judgment in adjusting weight on and in the boat.
Pay attention to how the weight is distributed on and in the boat at all
times, particularly when engaged in water sports. Too much ballast, gate
and passengers to one side of the boat could create an unstable condition
that could result in an unsafe situation for all. Even in making waves,
care must be taken to put safe operation rst.
Never place objects on a Surf Gate or try to use a Gate to support a person’s weight. The
Surf Gates are not manufactured or mounted to accept additional weight.
Never add any weight to a Surf Gate, nor use one to hold a person’s
weight. The Surf Gate cannot sustain added weight on it, and subse-
quent damage to the Surf Gate or transom of the boat as a result will
not be covered under warranty.
If there is a malfunction of the Surf Gates, an alarm will sound through the instrument
panel. The volume of the transition alarm is controlled through the stereo controls and emits
through the tower speakers. If the boat is not equipped with tower speakers, or if
it is equipped with tower speakers but they are turned OFF, the alarm cannot be
heard.
The Surf Gates should always be retracted when not in use.
Models: (Optional) The Surf Gates are an option available on all models.
Beneath the boat are several critical components for the proper and safe
operation of the boat. In general, consumers do not have to give these items at-
tention beyond routine checks and maintenance, but if any of them are damaged, it
can result in a truncated outing.
The rudder is part of the steering system. The steering wheel turns the rudder
in the direction that the driver wishes to steer. More information about the steering system is
Axis
Owners
Manual
2019
Page 107
underwater gear
(rudder, fins,
strut, propeller,
paddlewheel and
raw-water intake/
sea strainer)
