AXISM32-LVENetworkCameraSeries
Congureyourdevice
•AXISI/OIndicationLED
•AnAxisnetworkvideocamera
注
AXISI/OIndicationLEDshouldbeconnectedtoanoutputport.
注
ForinstructionsonhowtoconnecttheAXISI/OIndicationLED,seetheinstallationguideprovided
withtheproduct.
ThefollowingexampleshowshowtoconfigurearulethatturnsontheAXISI/OIndicationLEDtoindicate
thatcameraisrecording.
1.GotoSystem>Accessories>I/Oports.
2.MakesurethattheportyouconnectedtheAXISI/OIndicationLEDtoissettoOutput.Setthe
normalstatetoCircuitopen.
3.GotoSystem>Events.
4.Createanewrule.
5.SelecttheConditionthatmustbemettotriggerthecameratostartrecording.Itcan,forexample,
beatimescheduleormotiondetection.
6.Inthelistofactions,selectRecordvideo.Selectastoragespace.Selectastreamprofileor
createanew.AlsosetthePrebufferandPostbufferasrequired.
7.Savetherule.
8.CreateasecondruleandselectthesameConditionasinthefirstrule.
9.Inthelistofactions,selectToggleI/Owhiletheruleisactive,andthenselecttheporttheAXIS
I/OIndicationLEDisconnectedto.SetthestatetoActive.
10.Savetherule.
OtherscenarioswhereAXISI/OIndicationLEDcanbeusedareforexample:
•ConfiguretheLEDtoturnonwhenthecamerastarts,toindicatethepresenceofthecamera.
SelectSystemreadyasacondition.
•ConfiguretheLEDtoturnonwhenlivestreamisactivetoindicatethatapersonoraprogramis
accessingastreamfromthecamera.SelectLivestreamaccessedasacondition.
Setuptheintrusionalarm
重要
TosetupanintrusionalarmyouneedtheAXISDomeIntrusionSwitchC.
Withadomeintrusionswitchmountedinsidethecamera,youcanreceiveanotificationifsomeone
removesthecameradome.
Beforeyoustart
•Connecttheintrusionalarmswitchtopin1(ground)andpin3(digitalinput)ofthecamera’s
I/Oconnector.
Configuretheinputport
1.GotoSystem>Accessories>I/Oports.
