Axis M32-LVE Series User Manual

AXISM32-LVENetworkCameraSeries
Specications
FunctionPinNotes
Specifications
DCground
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.Note:
Thispincanonlybeusedaspowerout.
12VDCMaxload=25mA
DigitalInput
3
Connecttopin1toactivate,orleavefloating
(unconnected)todeactivate.
0tomax30VDC
DigitalOutput
4
Internallyconnectedtopin1(DCground)
whenactive,andfloating(unconnected)when
inactive.Ifusedwithaninductiveload,e.g.,a
relay,connectadiodeinparallelwiththeload,
toprotectagainstvoltagetransients.
0tomax30VDC,open
drain,100mA
示 示
示
例 例
例
1
DC ground
2
DC output 12 V, max 25 mA
3
Digital input
4
Digital output
59

Axis M32-LVE Series Specifications
