AXISP3346-VFixedDomeNetworkCamera
TechnicalSpecifications
Connectors
I/OConnector
4-pinterminalblockfor:
Auxiliarypower(DCoutput)
DigitalInput
DigitalOutput
0VDC(-)
4 3 2 1
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
3.3VDC
Maxload=50mA
DigitalInput
3
Connecttopin1toactivate,orleaveoating(unconnected)
todeactivate
0tomax40VDC
DigitalOutput
4
Connectedtopin1whenactivated,oating(unconnected)
whendeactivated.Ifusedwithaninductiveload,e.g.arelay,
adiodemustbeconnectedinparallelwiththeload,for
protectionagainstvoltagetransients.
0tomax40VDC,opendrain,
100mA
3.3 V max 50 mA
1
2
3
4
AudioConnector
3.5mmaudioconnectors
(stereo)
123
62
