AXISP3364-LVNetworkCamera
PowerConsumption
Note
MakesuretheswitchonthebottomofthecameraisconguredtoPoEclass3.TheIR
illuminationwillnotworkifconguredotherwise.
ProductPoE
AXISP3364-LV
PoweroverEthernetIEEE802.3af/802.3atType1
IRilluminationon:Class3;max12.1W
IRilluminationoff:Class2;max5.9W
Connectors
I/OConnector
4-pinterminalblock
1 2 3 4
Foranexamplediagram,seeConnectionDiagramsonpage15.
FunctionPinNotes
Specications
0VDC(-)
1
0VDC
DCoutput
2
Canbeusedtopowerauxiliaryequipment.
Note:Thispincanonlybeusedaspowerout.
3.3VDC
Maxload=50mA
Digitalinput
3
Connecttopin1toactivate,orleaveoating
(unconnected)todeactivate
0tomax40VDC
Digital
output
4
Connectedtopin1whenactivated,oating
(unconnected)whendeactivated.Ifused
withaninductiveload,e.g.arelay,adiode
mustbeconnectedinparallelwiththeload,
forprotectionagainstvoltagetransients.
0tomax40VDC,open
drain,100mA
AudioConnector
3.5mmaudio
connectors(stereo)
123
