26
AXIS Q6032-E - Events
Continue image upload (unbuffered) - enables the upload of video images for a fixed length of time. Specify the length of
time for the uploaded recording, in seconds, minutes or hours, or for as long as the trigger is active. Finally, set the desired
image frequency to the maximum (the maximum available) or to a specified frame rate. The frame rate will be the best
possible, but might not be as high as specified, especially if uploading via a slow connection.
Scheduled Event
A Scheduled event can be activated at preset times, in a repeating pattern on selected weekdays.
Configuration example:
The following example describes how to set up a scheduled event.
1. Go to Set
up > Events > Event Types.
2. Click the Add scheduled... button. The Scheduled Event Type Setup page appears.
3. Enter a descriptive Name for the event, such as ‘Scheduled e-mail upload’.
4. Set the Priority (High, Normal or Low).
5. Set the Activation Time parameters (24h clock) for the event - start on Sundays at 13.00 with a duration of 12
hours.
6. Set the When Activated... parameters, (what the camera would do at the specified time) for example, send
uploaded images to an e-mail address.
7. Click OK to save the Event in the Event Types list.
Please see the online help for descriptions of each available option.
Motion Detection
Motion detection is used to generate an alarm whenever movement occurs (or stops) in the video image. A total of 10 Include
and/or Exclude windows can be configured.
• Included windows target specific areas within the whole video image
• Excluded window
s define areas within an Include window that should be ignored (areas outside Include windows are
automatically ignored)
Once configured, the motion detection windows appear in the
list of available triggers, for triggering events. See How to set
up a triggered event, on page 25.
Note:
Usi
ng the motion detection feature may decrease the camera’s overall performance.
