AXISQ60Series
•Becarefulnottoscratch,damageorleavengerprintsonthedomecoverbecausethis
coulddecreaseimagequality.Ifpossible,keeptheprotectiveplasticonthedomecover
untiltheinstallationiscomplete.
Changethedomecover(optional)
Thepremountedcleardomecovercanbereplacedifyouwanttousethesmokeddomecoveror
ifthedomecoverisscratchedordamaged.SparedomecoverscanbepurchasedfromyourAxis
reseller
Forlocationofthecomponents,seeHardwareoverviewonpage12.
1.Loosenthedomeringscrewsandremovethedomecover.
2.Removethedomebracketscrews,thedomebracket,andthedomecoverfromthedome
ring.
3.Attachthedomebracketandthedomecovertothedomeringandtightenthescrews
(torque1.2Nm).
4.ToinstallanSDcard,seeHowtoinstallanSDcard(optional)onpage21.
5.Attachthedomecovertothetopcoverandtightenthescrews(torque1.5Nm).
HowtoinstallanSDcard(optional)
InstallinganSDcardisoptional.AstandardorhighcapacitySDcard(notincluded)canbeusedto
storerecordingslocallyintheproduct.
1.Loosenthedomeringscrewsandremovethedomecover.
2.InsertanSDcardintotheSDcardslot.
3.Attachthedomecovertothetopcoverandtightenthescrews(torque1.5Nm).
Howtoinstallthecamera
TheAxisproductcanbemountedwiththecablesroutedthroughoralongthewallorceiling.
Chooseoneofthefollowingwaystoinstallyourcamera:
•Installthecamerawithahardceilingmountonpage21.
•Installthecamerawithadropceilingmountonpage23.
•Installthecamerawithabracketmountonpage25.
Installthecamerawithahardceilingmount
1.Preparetheceilingforinstallationofthemountingplate.Usethemountingplateas
atemplatetopositiontheholes.Makesuretousedrillbits,screwsandplugsthat
areappropriateforthematerial.
21
EN
