Axis Q6044 Installation Guide

AXISQ60Series
10.Slidetheunitholdersonthenetworkcameraintotheslotsinthemountingplateand
rotatethecameraunit.
11.Installthesuppliedmidspan,seetheInstallationGuidedeliveredwiththemidspanor
nditonwww.axis.com
12.Installtheceilingtilewiththecameramountedonit.
13.Putthetrimringontheceilingbracketandtightenthescrews.
1
Trimring
2
TrimringscrewT20(4x)
Installthecamerawithabracketmount
1.Installtheselectedbracketaccordingtotheinstructionssuppliedwiththebracket.If
drillingisrequired,makesuretousedrillbits,screwsandplugsthatareappropriatefor
thematerial.
2.Loosenthecamerabaselidscrewsandremovethecamerabaselid.
3.Routethenetworkcableand,ifused,themulti-connectorcablethroughtheholes
inthemountingbracket.
4.Securethecamerausingthesuppliedsafetywire.
25
EN
