Axis Q7424-R MK II User Manual

AXISQ7424-RMkIIVideoEncoder
Digitalinput–Connecttopin1toactivate,
orleaveoating(unconnected)todeactivate.
0tomax30VDC Congurable
(Inputor
Output)
3–
6
Digitaloutput–Connectedtopin1when
activated,oating(unconnected)when
deactivated.Ifusedwithaninductiveload,
e.g.arelay,adiodemustbeconnectedin
parallelwiththeload,forprotectionagainst
voltagetransients.
0tomax30VDC,open
drain,100mA
1
2
3
A
B
D
S
G
1
0VDC(-)
2
DCoutput12V,max125mA
3
Example:pushbutton
A
I/Oconguredasinput
B
I/Oconguredasoutput
AudioConnector
4-pinterminalblockforaudioinputandoutput.
Foraudioin,theleftchannelisusedfromastereosignal.
18
