5.Forconduitinstallationsonly:removethetwoconduitcoverclipsfollowedbythe
conduitcover.
6.Attachthebaseunittothemountingsurfacewithappropriatefastenersinthefour
screwholes.
Routethecables
WARNING
Riskofelectricshock.Theproductshallbegroundedusingboththeprotectivegrounding
wireinthepowercableandthegroundingbraid.Makesurebothendsoftheprotective
groundingwireandthegroundingbraidareincontactwiththeirrespectivegrounding
surfaces.
Important
Useonlycablesthatcomplywiththespeciedcablearea.Formoreinformation,see
Cablethicknessonpage22.
1
Powercable(notincluded)
2
Strainrelief
3
Groundingscrew
4
Groundingbraid(notincluded)
5
Bottomcablehole
