Axon Fleet 3 Wireless Microphone Installation and User Manual
Axon Enterprise, Inc. Page 5 of 28
Introduction
The Axon Fleet 3 Wireless Microphone is a hardware solution for audio capture outside of the Fleet
3-equipped vehicle where Axon Body Worn Cameras have not been deployed. The Charge Base is
mounted in the vehicle, connected to the hub via ethernet, and handles all charging and data needs
for the Wireless mic while docked. The Charge base also facilitates all pairing and audio
communication to the microphone while in use. The Axon Fleet 3 Hub can support up to 2 Wireless
Microphones and 2 Charge bases per vehicle.
Wireless Microphone Performance:
• The Wireless Microphone has a range of 1,000ft (300m) with unobstructed line-of-
sight and at least 500ft (150m) with a person and vehicle obstruction.
• When fully charged, the Wireless Microphone will last 12 hours. When inserted in the
Charging Base, a Wireless Microphone will recharge to 85% within 90 minutes.
• Wireless Microphone uses the Axon Rapidlock mounting solution, sharing all the
same mounting configurations as Axon Body Worn cameras.
• The Wireless Microphone is shipped with an optional lapel microphone, which
provides superior audio capture quality and wind noise cancellation.
Axon Fleet 3 Wireless Microphone Hardware Kit
The FLEET 3 WIRELESS MICROPHONE KIT – SKU 72035 – includes the following components:
FLEET 3 WIRELESS MIC, CHARGING BASE
FLEET 3 WIRELESS MIC, CHARGING BASE, REMOTE ANTENNA
FLEET ETHERNET CABLE, CAT6, 20 FT
FLEET 3 WIRELESS MIC, LAPEL MIC
Charging the Axon Fleet 3 Wireless Microphone Outside of the Vehicle
Axon offers a solution for charging the Wireless Microphone outside of the vehicle. The hardware kit for this
consists of an AC PoE Injector and Charging base, If you wish to supplement your in-vehicle charging with in-office
charging, please purchase an additional Charging base and an injector for each device you wish to charge.
FLEET 3 WIRELESS MIC, AC POWER POE INJECTOR
