Chapter 4: Wall Mounting an Axon Dock 16
TASER Axon Dock Installation Manual
ment.
2 Choose a location close to an electrical outlet and a network outlet (see Step 3: Connect to the
Network (Chapter 3) for a picture of an Internet port). Measure the length of the dock’s
power cord to be sure that it will reach.
Step 4: Attach the Wall Mount Bracket to the Wall (Stud mount)
Your Wall Mount Kit comes with hardware for mounting the bracket to a stud or mounting directly
into drywall. If you are going to install the bracket to drywall, go to Step 5: Attach the Wall Mount Brack-
et to the Wall (Drywall Mount).
Note: Use the longer screw for mounting the bracket into a stud.
1 Using a stud nder, mark the location of each stud’s center with a pencil.
2 Use a nail to conrm a stud has been located.
Note: Depending on the wall construction, you may not be able to mount both ends of the
Wall Mount Bracket into the stud.
3 Use the drywall anchors in the Wall Mount Kit for the other mounting locations if needed.
4 Position the Wall Mount Bracket on the wall and align the mounting keyhole in the left side of
the bracket with the center line of the stud.
5 Use a level to ensure the bracket is level before marking the holes.
6 Mark the center of the left side keyholes in the center of each wall stud.
7 Using a power drill, drill a pilot hole smaller than the screw diameter.
8 Install the screws into the stud until there is 1/8” (3.2 mm) of space between the bottom of the
screw head and the wall.
This will allow the bracket to be placed onto the screws and settle in the keyhole (the holes in
the bracket are shaped like keyholes to make it easier to adjust the mount’s position on the
wall).
9 Repeat steps 5–8 for the other side of the mount bracket.
10 After the Wall Mount Bracket is positioned correctly, tighten all of the screws.
11 Go to Step 6: Connect the Cables.
Step 5: Attach the Wall Mount Bracket to the Wall (Drywall Mount)
Your Wall Mount Kit comes with hardware for mounting the bracket to a stud or mounting directly
into the drywall. If you are installing the bracket to a wall stud, go to Step 4: Attach the Wall Mount
Bracket to the Wall (Stud mount).
Note: Use the screw-in anchors and shorter screws for drywall installation.
1 Find the location where you want to mount the Wall Mount Bracket.
2 Locate the Wall Mount Bracket on the wall.
3 Use a level to ensure the bracket is level before marking the holes.
4 Mark the center of the four keyholes on the wall.
