Chapter 4: Wall Mounting an Axon Dock 17
TASER Axon Dock Installation Manual
5 Remove the Wall Mount Bracket and screw in the drywall anchors in each location.
6 Screw in each of the screws until there is 1/8” (3.2 mm) of space between the bottom of the
screw head and the wall.
7 This will allow the bracket to be placed onto the screws and settle in the keyhole.
Step 6: Connect the Cables
1 There is space provided on the horizontal shelf to secure the power supply for the dock.
2 Position the power supply between the slots in the bracket and secure the power supply to the
bracket with the Velcro strap.
3 Route the barrel connector around the edge guard and plug the barrel connector into the pow-
er jack on the dock.
4 You can secure the cable in position with the attached zip tie and the associated slots in the
bracket.
5 Plug the power supply cable into a power strip or nearby AC outlet.
6 Plug the CAT 5e (or better) cable from your agency’s network data jack into the WAN port on
the dock.
7 You can secure the cable in position with the attached zip tie and the associated slots in the
bracket.
