3
REV. 6/26/2018 INSTAX-ADFD01
CONNECTIONS TO BE MADE (CONT.)
The following (3) wires are only for multimedia/navigation radios that require these wires.
Connect the Blue/Pink wire to the VSS/speed sense wire.
Connect the Green/Purple wire to the reverse wire.
Connect the Light Green wire to the parking brake wire
Tape off and disregard the following (4) wires, they will not be used in this application:
Green, Green/Black, Purple, Purple/Black
From the AX-ADFD01 harness to the aftermarket radio:
Connect the Black wire to the ground wire.
Connect the Yellow wire to the battery wire.
If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red wires
to accessory power.
Connect the Blue wire to the power antenna wire.
Tape off and disregard the Blue/White wire with a red connector, it will not be used in
this application.
Connect the Green wire to the left rear positive speaker output.
Connect the Green/Black wire to the left rear negative speaker output.
Connect the Purple wire to the right rear positive speaker output.
Connect the Purple/Black wire to the right rear negative output.
If the vehicle is equipped with satellite radio or SYNC, and desired to be retained, connect
the Red and White RCA jacks labeled “RSE/SYNC/SAT” to the audio AUX-IN jacks.
Note: Most Ford radios have satellite radio built into the radio, so this feature is lost if so.
If the vehicle is equipped without SYNC, and the AUX-IN jack is desired to be retained,
connect the Red and White RCA jacks labeled “FROM 3.5” to the audio AUX-IN jacks.
If the vehicle is equipped with a factory subwoofer, connect the White RCA jack labeled
“SUBWOOFER” to the subwoofer out jack.
Disregard the Red RCA jack labeled “CENTER CHANNEL”, it will not be used in this application
.
12-pin pre-wired ASWC-1 harness:
This harness is to be used along with the optional ASWC-1 (sold separately) to retain steering
wheel audio controls. If the ASWC-1 is not being used, disregard this harness. If the ASWC-1
will be used, please refer to the ASWC-1 instructions for radio connections and programming.
Disregard the harness that comes with the ASWC-1.
DIN jack:
The DIN jack is to be used with the optional AX-LCD (sold separately) to retain satellite radio or
SYNC information.
Continue to Installing & Programming the AX-ADFD01
