APPLICATIONS CONNECTIONS TO BE MADE
Attention! This interface will work with models that are either non-amplified, or amplified.
Please follow the instructions carefully for your model vehicle. Failure to do so will result in
either no sound, or low sound. If you are unsure if your vehicle is factory amplified or not, please
contact your local dealership.
For models
without
a Sony/THX amplifier:
From the 16-pin harness with stripped leads to the aftermarket radio (harness included with interface):
• Connect the Red wire to the accessory wire.
Note: If installing either an ASWC-1 or AX-LCD (both sold separately), connect the (2) Red
wires on the AX-ADFD01 harness as well.
• If the vehicle is equipped with a factory subwoofer, connect the Blue/White wire to the
amp turn on wire.
• If the aftermarket radio has an illumination wire, connect the Orange/White wire to it.
• If the aftermarket radio has a mute wire and the vehicle is equipped with SYNC, connect
the Brown wire to it. If the mute wire is not connected, the radio will turn off when SYNC
is activated.
• Connect the Gray wire to the right front positive speaker output.
• Connect the Gray/Black wire to the right front negative speaker output.
• Connect the White wire to the left front positive speaker output.
• Connect the White/Black wire to the left front negative speaker output.
Continued on the next page
FORD
Econoline * 2014-up
Econoline 2009-2013
Edge (with NAV) 2007-2010
Escape 2008-2012
Expedition 2007-2014
Explorer (with NAV) 2009-2010
Explorer Sport Trac (with NAV) 2009-2010
F-150 * 2009-2012
F-150 STX/FX2 base/XLT base 2013
F-150 STX/XLT base 2014
F-250/350/450/550 XL/XLT * 2013-2016
F-250/350/450/550 (with NAV) 2011-2012
F-650/750 * 2016-up
Focus 2008-2011
Fusion 2010-2012
Mustang 2009-2014
Taurus 2010-2012
LINCOLN
MKX 2007-2010
MKZ 2007-2009
Navigator 2007-2014
MAZDA
Tribute 2008-2011
MERCURY
Mariner 2008-2011
Milan 2010-2011
Mountaineer (with NAV) 2009-2010
* With AM/FM/CD radio
