Attention! The AX-ADFD01 will work with both the AX-ADBOX1 and AX-ADBOX2 interfaces, but
programming will be different. Refer to the proper page for whichever interface is being used.
Also note, the programming instructions for the AX-ADBOX2 reflect gen. 2. If installing a gen. 1 AX-
ADBOX2, refer to the AX-ADBOX1 programming instructions. Gen. 2 interfaces can be distinguished
by a blue reset button between the (2) connectors.
AX-ADBOX2
Installing the AX-ADFD01
With the key in the off position:
•
Connect the 16-pin harness with stripped leads, and the AX-ADFD01 harness, into the interface
.
• If an ASWC-1 (sold separately) will be used, do not connect it until the AX-ADFD01 is
programmed and fully functional.
Attention! Do not connect the AX-ADFD01 harness to the wiring harness in the vehicle just yet.
Programming the AX-ADFD01
For the steps below, the L.E.D. located inside the interface can only be seen while active.
The interface does not need to be opened to see the L.E.D.
1. Start the vehicle.
2. Connect the AX-ADFD01 harness to the wiring harness in the vehicle. The L.E.D. will
initially be Green to indicate the interface is powered.
3. After a few seconds the L.E.D. will turn on solid Red while the interface automatically
programs to the vehicle. The radio will shut off at this point. This process should take 5 to
30 seconds.
4. After the interface is programmed, the L.E.D. will turn on solid Green, and the radio will
come back on, indicating programming was successful.
5. Test all functions of the installation for proper operation, before reassembling the dash.
6. If the interface fails to function, refer to “Troubleshooting”, “Resetting the interface”.
Troubleshooting
Resetting the interface
1. The Blue reset button is located inside the interface, between the two connectors. The
button is accessible outside the interface, no need to open the interface.
2. Press and hold the reset button for two seconds, then let go to reset the interface.
3. Refer to “Programming the AX-ADFD01 Interface” from this point.
Continue to Adjusting the AX-ADFD01
INSTALLING & PROGRAMMING THE AX-ADFD01
