Installation & User Guide
AX200 Installation & User Guide – July 2007
12
recommended that the segment address is 10.1.1.x Use the subnet mask as 255.255.255.0 and
the gateway IP address should be 0.0.0.0
WAN Configuration
When working on a wide area network (WAN) all devices that are configured to operate with fixed
IP address such as the AX200 controller, will probably have a different segment address. So if
the Server (PC) IP address is 10.1.1.15 then the AX200 will require an IP address with the
appropriate segment such as 10.1.2.52. Use the subnet mask as 255.255.255.0 and the gateway
IP address must be configured (Please consult the Network Administrator for all IP Settings)
VPN Configuration
Generally configure Virtual Private networks as per the LAN Configuration setup. (Please consult
the Network Administrator for all IP Settings)
Example IP Address Table
Device Name Location IP Address
Gateway
Address
Subnet Mask
Address
File & Printer Server
Sales PC
AX200 PC
AX200 Controller
AX200 Controller
File & Printer Server
Sales PC
AX200 Controller
AX200 Controller
London
London
London
London
London
New York
New York
New York
New York
10.1.1.10
DHCP
10.1.1.35
10.1.1.36
10.1.1.37
10.1.2.10
DHCP
10.1.2.55
10.1.2.56
10.1.1.1
DHCP
10.1.1.1
0.0.0.0
0.0.0.0
10.1.2.1
DHCP
10.1.2.1
10.1.2.1
255.255.255.0
DHCP
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
DHCP
255.255.255.0
255.255.255.0
AX200 & i-BOX Connections
9 Way i-BOX I/O Connection
Table below describes the 9 way connector on the i-BOX and states the functionality of each pin.
9 WAY D DESCRIPTION NOTES COLOUR
1 Not connected
2 Breakglass 2 (switched) + 12v (pin 3) Blue
3 + 12v D.C Red
4 Relay 2 Output goes low when active Purple
5 * Ground White
6 Fire Input (switched) + 12v (pin 3) Orange
7 Breakglass 1 (switched) + 12v (pin 3) Green
8 Relay 3 Output goes low when active Yellow
9 Relay 1 Output goes low when active Black
