Before installing the SVP, check for:
Variations
Use the appropriate mounting plate and feedback lever length for the
actuator.
Clearance
Do not install the SVP in such a place that it will be difficult to maintain or
that will interfere with piping, wiring, or adjustment.
Check for mechanical interference and valve operating clearance.
Orientation
Install the SVP in the correct direction. Avoid installation where the left of
the SVP (where pilot relay is located) would be on top.
Fragility
Damage to the SVP may result from excessive impact or force. Do not
force the feedback lever or bend the feedback pin.
Secureness Be sure to tighten bolts and nuts securely on the SVP and control valve.
